Split Core Current Transducers - CR5220S

• Current: DC Current
• Frequency: DC Frequency
• Split Core: True
• RMS: N/A
• Elements: Single Element
• Outputs: 4-20 mA DC
• Power: 24 Vdc Power
• Hall Effect: Hall Effect
• Mount: DIN Rail Mount, Panel Mount

  • Model Number: CR5220S
  • Data Sheet: Date Sheet File
Quantity:
- +
  • Split Core Current Transducers
Mouse over image to zoom

Product Specification

CR5220S DC Current Sensing Transducers are designed to provide a DC signal which is proportional to a DC sensed current. These devices are designed for direct current only, targeting them towards general and daily applications. The ranges 2 to 10 Amp utilize an advanced Magnetic Modulator technology and the ranges 20 amps and above utilize Hall Effect technology. The CR5220S has a 4-20 mAdc output that is ideal for battery charging applications.

CR5220S Split Core Current Transducers Features
• 4-20 mA DC output output
• 24 Vdc powered
• Highest precision available
• Connection diagram printed on case

CR5220S Split Core Current Transducers Specifications
• Basic Accuracy: 1.0%
• Calibration: True RMS Sensing, Average RMS, DC
• Thermal Drift: 500 PPM/°C
• Operating Temperature: 0°C to +60°C
• Installation Category: CAT II
• Polution Degree: 2
• Insulation Voltage: 2500 Vdc
• Altitude: 2000 meter max.
• Frequency Range: DC Only
• MTBF: Greater than 100 K hours
• Cleaning: Water-dampened cloth
• Supply Voltage: 24 Vdc ±10%
• Output Load: 0 to 300 Ω
• Response Time: 250 ms max. 10-100% Full Scale
• Relative Humidity: 80% for temperatures up to 31°C and decreasing linearly to 50% at 40°C

CR5220S Split Core Current Transducers Applications
• Battery chargers and systems
• DC motor drives
• Power Supply Management
• Mobile Applications

CR5220S Split Core Current Transducers PART NUMBERS
