Infrared Gas Analysis Module - RL-H150

• Design of imported light source and dual-channel detector, built-in temperature compensation, with long life, high precision, fast response,good stability and so on
• Small module, compact structure, easy to install

  • Model Number: RL-H150
  • Data Sheet: Date Sheet File
Quantity:
- +
  • Infrared Gas Analysis Module
Mouse over image to zoom

Product Specification

RL-H150 Infrared Gas Analysis Module Applications:

    It is widely used in gas analysis in cement and metallurgical industry, greenhouse and scientific laboratory gas analysis in greenhouse, chemical fertilizer and chemical industry, gas analysis in industrial process, gas composition gas analysis in flue gas, environmental monitoring, medical monitoring, exhaust analysis, etc.



RL-H150 Infrared Gas Analysis Module Features:

• Design of imported light source and dual-channel detector, built-in temperature compensation, with long life, high precision, fast response,good stability and so on

• Small module, compact structure, easy to install

• Advanced technology, high cost-performance



RL-H150 Infrared Gas Analysis Module Technical parameters:

Measurement principle: NDIR principle

Measurement components and ranges:

RL-H150 measurement components and ranges

Gas component

model number

measuring range

remarks

CO2

RL-H150CO2

0~10%/30%/50%/100%

Range optional

CO

RL-H150CO

0~10%/30%/50%/100%

Range optional

CH4

RL-H150CH4

0~10%/30%/50%/100%

Range optional

C3H8

RL-H150C3H8

0~10%/30%/50%/100%

Range optional

SF6

RL-H150SF6

0~10%/30%/50%/100%

Range optional

NH3

RL-H150NH3

0~10%/30%/50%/100%

Range optional


Resolution :0.01 per cent (based on range of measurements)

Linear error:FS;±2 per cent

Stability:zero drift ±2% FS;

                 range drift ±2% FS;

Repeatability: FS;±1 per cent;

Sample gas flow:200~800 ml/ min;

Response time:T90≤10 seconds;

Working voltage:6 VDC±5;

Drive current: less than 140 MA;

Air intake mode:continuous air intake;

Sample gas temperature:0℃~+50℃;

Working environment: temperature:-10℃~+50℃

Humidity:≤90 per cent;

Preheat time:3 min;

Mode of communication:sensor with digital output Modbus ASCII 3.3VDC TTL, can achieve two-way communication with computer ;(external output board output 4-20 mA or RS485)

Shape size:RL-H150:62mm( length)×33 mm( width)
