Pressure & Temperature Integrate Transmitter - JQWY

• Pressure Measuring range: 0~110kPa
• Temperature Measuring range: 0°C~50°C
• Power supply: DC 24V (18V~32V)
• Environment temperature: 0°C~50°C
• Pressure Response time: ≤ 50ms
• Temperature Response time: ≤ 2s
• Hysteresis and repeatability: ± 0.2%F.S
• Nonlinear: ± 0.2%F.S

  • Model Number: JQWY
- +
  • Pressure & Temperature Integrate Transmitter
  • Pressure & Temperature Integrate Transmitter
Mouse over image to zoom

Product Specification

JQWY Pressure & Temperature Integrate Transmitter Introduction
Suitable for all kinds of environment atmospheric pressure and temperature combined measurement.

JQWY Pressure & Temperature Integrate Transmitter Characteristic
• Have good stability for a long time
• Have intelligent digital circuit compensation and wide usage temperature
• Prevent surge voltage and reverse polarity protection
• Have anti-jamming design
• High sensitivity and low temperature drift
• Can match LCD  at site

JQWY Pressure & Temperature Integrate Transmitter Parameters

Measuring range Pressure: 0~110kPa
Temperature: 0°C~50°C
Power supply DC 24V (18V~32V)
Accuracy  Pressure: ± 0.25%
Temperature: ± 1°C
Load capacity ≤ 500Ω
Environment temperature 0°C~50°C
Response time Pressure ≤ 50ms
Temperature ≤ 2s
Hysteresis and repeatability ± 0.2%F.S
Long-term stability ± 0.1%F.S/y
Nonlinear ± 0.2%F.S
Thermal zero drift ± 0.02%F.S/°C
Over load pressure two times of range
Electrical connection cable
Measuring medium air
